Features of the 4K HDMI fiber optic transmitter PTN FOUH302T at a glance
- Support HDMI 1.4, support 4Kx2K & 1080p 3D signals
- HDCP Compliant
- High data rate: 10.2 Gbps
- Transmits HDMI/DVI and stereo audio
up to 1km over singlemode fiber and
up to 300m over multimode fiber - The PTN FOUH302T supports powerful EDID configurations, 10 types in total (8 for HDMI and 2 for DVI)
- Supports audio signal management (choice of embedded HDMI audio or external stereo audio)
- Embedded HDMI audio support Dobby (TrueHD) / DTS formats (HD master), the audio input for external stereo audio signals supports the PCM format
- Supports FiberOptical Module.
- Firmware upgrade possible via micro USB port
- Support hot plug
| inputs | |
| inputs | 1x HDMI 1x analog audio (stereo) |
| connections | 1x HDMI socket 1x 3.5 mm jack socket (stereo audio) |
| input signal | HDMI (DVI compatible), Stereo Audio & PCM |
| exits | |
| exits | 1x fiber |
| connections | 1x XFP Fiber Connector |
| output signal | fiber |
| Miscellaneous | |
| fiber modules | Single mode fiber optic modules Multimode fiber optic modules |
| bit depth | 8,10,12 bits |
| HDCP | Compatible with HDCP Uses the DVI and HDMI standards |
| standards | HDMI 1.4, DVI 1.0, HDCP 1.4 |
| Optical Fiber Modules | |
| Optical fiber and transmission distance | 1 km (maximum, single mode fiber optic, suitable for single mode fiber optic modules) 300 m (maximum, OM3 multimode fiber optic) |
| Resolution via fiber | Supports resolutions up to 4Kx2K |
| fiber connectors | LC Fiber Connector |
| data rate | 10.2 Gbps (Max) |
| Electricity | |
| power supply | via external power supply (included) |
| power adapter | Input: AC 100ļ½240V, 50ļ½60Hz Output: DC 5V 1A |
| power consumption | 3.1W (maximum) |
| Environmental conditionsĀ Ā | |
| humidity | 10% to 90% relative humidity |
| operating temperatur | 0ā to 45ā |
| physical characteristics | |
| Housing | metal |
| Dimensions (WxHxD) | 120*32*80mm |
| Weight | approx. 240g (0.24kg) |
Supported video formats of the FOUH302T from PTN
| resolution | HDMI | DVI |
|---|---|---|
| 480i | ā | ā |
| 480p | āĀ | ā |
| 576i | ā | ā |
| 576p | ā | ā |
| 720p | ā | ā |
| 1080i | ā | ā |
| 1080p | ā | ā |
| 4Kx2K | ā | Ā |
| 1080p 3D @ 60Hz | ā | Ā |
